Mono Power Amplifier for High Loads
The CI-NAP 101 is designed for applications where a single channel needs to deliver a lot of power. With 500 watts into 8 ohms and 800 watts into 4 ohms, it is particularly suitable for power-hungry loudspeakers and subwoofers in professional installations.
Also for Line and High-Impedance Systems
In addition to classic low-impedance amplification, the model also supports 70V and 100V systems. This significantly expands the range of applications and makes the power amplifier interesting for integrated sound reinforcement solutions where flexible distribution and long cable runs are required.
Clean and Controlled Operation
With a high signal-to-noise ratio, very low distortion, and a wide frequency response, the amplifier remains precise even at high levels. This is particularly important when the power amplifier is continuously operating in rack environments and should also remain tonally unobtrusive.
Installation-Friendly Design
The combination of stereo RCA input, Euroblock outputs, signal detection with automatic shutdown, and universal power supply makes integration straightforward. This allows the CI-NAP 101 to be cleanly integrated into demanding installation systems without creating unnecessary complexity.
Technical data
|
Product Type
|
Mono Power Amplifier |
|
Channels
|
1 |
|
Power 8 Ohm
|
500 W |
|
Power 4 Ohm
|
800 W |
|
70V / 100V
|
150 W / 240 W |
|
Frequency Response
|
3 Hz to 70 kHz |
|
THD+N
|
< 0.008 % at 1 kHz |
|
Signal-to-Noise Ratio
|
110 dB |
|
Inputs
|
Stereo RCA |
|
Outputs
|
Stereo RCA, Low Impedance Euroblock, 70V Euroblock, 100V Euroblock |
|
Idle Power Consumption
|
0.5 W in standby |
|
Weight
|
8.9 kg |
