- For medium-mass tonearms
- Ruby cantilever
- Fritz Gyger 70 stylus
- Coils made of pure silver wire
Comfortably Analytical
Compared to the Ortofon MC Cadenza Red, the Fritz Gyger 70 stylus of the Ortofon MC Cadenza Blue extracts even more details from the groove, playing with more articulation without developing an unpleasant coldness in reproduction. Very pleasant and well-tempered!
Technical data
|
Model |
Ortofon MC Cadenza Blue |
|
Pickup Type: |
MC (low output moving coil) |
|
Output Voltage: |
0.50mV* |
|
Amplifier connector: |
Phono MC |
|
Channel deviation at 1 kHz: |
<1.2dB |
|
Crosstalk attenuation at 1kHz: |
>23dB |
|
Crosstalk attenuation at 15kHz: |
>15dB |
|
Frequency range: |
20-50,000Hz |
|
Frequency Response: |
20-20,000Hz +2dB/-1dB |
|
Sampling capability at 315Hz: |
80m** |
|
Needle Give: |
12µm/mN |
|
recomm. Tonearm Type: |
moderate |
|
Scan Diamond: |
Fritz Gyger 70, naked |
|
Fillet: |
r/R 6/70µm |
|
Tracking force range: |
22-27mN (2.2-2.7g) |
|
recomm. Tracking Force: |
25mN (2.5g) |
|
Scan Angle: |
20 degrees |
|
DC Resistance: |
5 ohms |
|
recomm. Terminator: |
50-200 ohms |
|
Case material: |
Stainless steel/aluminium |
|
Height: |
18mm |
|
Weight: |
10.7g |
|
Special features: |
Pure silver wire winding, ruby ??cantilever |
|
*at 1000Hz, 5cm/sec. **at recommended tracking force |
|
