- For medium-mass tonearms
- Tapered aluminium cantilever
- Ortofon Replicant 100 stylus
- Aucurum coils
The Stabiliser
The Ortofon MC Cadenza Bronze features technical characteristics that are also found in Ortofon's "larger" MC cartridges. The increased stability in imaging compared to the Ortofon MC Cadenza Blue is particularly impressive. The Ortofon MC Cadenza Bronze plays distortion-free even with the most extreme dynamic leaps.
Technical data
|
Model |
Ortofon MC Cadenza Bronze |
|
Pickup Type: |
MC (low output moving coil) |
|
Output Voltage: |
0.40mV* |
|
Amplifier connector: |
Phono MC |
|
Channel deviation at 1 kHz: |
<1dB |
|
Crosstalk attenuation at 1kHz: |
>24dB |
|
Crosstalk attenuation at 15kHz: |
>20dB |
|
Frequency range: |
20-55,000Hz |
|
Frequency Response: |
20-20,000Hz ±1.5dB |
|
Sampling capability at 315Hz: |
80m** |
|
Needle Give: |
12µm/mN |
|
recomm. Tonearm Type: |
moderate |
|
Scan Diamond: |
Ortofon Replicant 100, naked |
|
Fillet: |
r/R 5/100 µm |
|
Tracking force range: |
22-27mN (2.2-2.7g) |
|
recomm. Tracking Force: |
25mN (2.5g) |
|
Scan Angle: |
23 degrees |
|
DC Resistance: |
5 ohms |
|
recomm. Terminator: |
50-200 ohms |
|
Case material: |
Stainless steel/aluminium |
|
Height: |
18mm |
|
Weight: |
10.7g |
|
Special features: |
Aucurum*** winding, conical aluminum cantilever, field stabilization element |
|
*at 1000Hz, 5cm/sec. **at recommended tracking force. ***Aucurum: Wire made of gold-plated, monocrystalline, oxygen-free 6N pure copper (OFC 99.9999%) |
|
