RME Fireface 802 FS – Central Studio Engine in Rack Format
The Fireface 802 FS has been consistently developed as the central hub for professional audio production. As a 19-inch rack interface, it is aimed at studios that require a fixed, reliable, and expandable audio control center.
Compared to desktop interfaces, the focus here is clearly on integration into fixed studio infrastructures: patchbays, outboard equipment, mixing consoles, and digital expansions can be seamlessly connected.
Flexible Studio Structure for Complex Signal Paths
The 802 FS is designed to efficiently manage large and complex audio setups. Multiple analog sources, digital devices, and external converters can be operated simultaneously without losing oversight.
This flexibility plays a central role, especially in classic recording studios or hybrid setups consisting of analog and digital technology.
FS Technology for Precise Signal Conversion
The FS generation at RME stands for optimized clocking and converter architecture. The result is a particularly stable, precise, and transparent audio reproduction.
This makes the interface interesting not only for recording but also for critical monitoring and mixing environments where absolute sound neutrality is required.
TotalMix FX – Complete Studio Control
Like all current RME interfaces, the 802 FS also features TotalMix FX. This allows all input and output signals to be freely routed, mixed, and controlled in real-time.
For studios, this means:
- flexible monitor paths
- individual headphone mixes
- complex submix structures
- complete control without external hardware
Who is the Fireface 802 FS for?
The 802 FS is clearly aimed at professional users with stationary studio setups:
- classic recording studios
- producers with hybrid setups
- broadcast and post-production
- mixing and mastering studios
It is not a mobile interface, but a fixed production hub.
Technical data
| Feature | Value |
|---|---|
| Recording / Playback Channels | 30x30 |
| Number of Microphone Inputs | 4 |
| Number of Line Inputs | 12 |
| Number of Instrument Inputs | 4 |
| Number of Line Outputs | 8 |
| Headphone Jacks | 2 |
| Phantom Power | Yes |
| S/PDIF Connections | 2 |
| ADAT Connections | 2 |
| AES/EBU Connections | 1 |
| MADI Connections | 0 |
| Ethernet | 0 |
| Other Interfaces | None |
| MIDI Interface | Yes |
| Word Clock | 1x In, 1x Out |
| Max Sample Rate | 192 kHz |
| Max Resolution | 24 bit |
| USB Bus-Powered | No |
| Incl. Power Supply | Yes |
| USB Version | 2.0 |
| Width | 483 mm |
| Depth | 242 mm |
| Height | 44 mm |
| Connection Format | USB Type B Socket |
